Product Details
Product Positioning
It utilizes the shear and compression between a rotating screw shaft, the inner barrel wall, and fixed blades to break large or irregular rubber blocks into smaller pieces. Simultaneously, high-pressure water provides powerful washing to remove sand and bark.
The machine significantly improves rubber cleanliness and provides initial dewatering, preparing the material for subsequent creping and granulation. It is widely used in the pre-treatment stages of TSR lines.
Product Advantages
Integrated Multi-Functionality: Combines crushing, washing, and conveying, simplifying the production flow and saving plant space.
Thorough Cleaning: Unique screw design ensures continuous tumbling and friction of the rubber, combined with water flushing for high impurity removal.
Powerful Compression Dewatering: Compresses rubber during transport to effectively reduce moisture content and the load on subsequent drying.
Large Processing Capacity: Designed for large-scale continuous production with a wide inlet for smooth feeding and high output.
Wear & Corrosion Resistant: Screw blades and liners are made from highly wear-resistant alloy for long service life and low maintenance costs.
Applicable Materials
Natural rubber coagulum, irregular rubber blocks, Cup Lump, field rubber, and other low-grade natural rubber feedstock.
Application Scenarios
TSR Production Lines: Used for raw material pre-treatment, connecting breakers and crepers.
High-Impurity Natural Rubber Cleaning Lines: Specialized for deep cleaning of raw materials with high impurity content.
Natural Rubber Pretreatment Lines: Used for initial crushing and cleaning before downstream washing and creping.
