Product Details
Product Positioning
Product Positioning: After repeated heat cycles, carbonized rubber residue accumulates on drying trolley surfaces and in corners, directly affecting the purity of subsequent batches. The TTR (Tropical Tree Rubber) Trolley Washer addresses three main pain points: low efficiency, hard-to-reach dead zones, and labor safety risks of manual cleaning.
Product Uses: The system uses an electric hoist to move trolleys into a temperature-controlled alkali soaking tank, where heat and chemicals soften and peel away stubborn residue. Trolleys are then moved to a rinsing zone for deep physical cleaning with multi-directional high-pressure water jets.
Typical Users: High-quality NR and TSR processing enterprises with strict impurity standards and high trolley turnover rates.
Product Advantages
Deep Cleaning without Dead Zones: Combining chemical softening with physical high-pressure rinsing, this system reaches internal walls and shelf gaps that manual brushing cannot.
Ensuring Final Product Quality: By preventing old carbonized residue from contaminating new rubber, it directly increases the yield of premium-grade products.
Reduced Labor Intensity: Replaces high-risk manual scraping in harsh environments with integrated mechanical handling, improving workshop occupational health and safety standards.
Applicable Product Types
Technically Specified Rubber (TSR), Natural Rubber (NR) (for their transport equipment)
Application Scenarios
At an export-oriented TSR 20 plant, manual cleaning was slow and ineffective for interior corners. After introducing the TTR system, a standardized 'unloading-soaking-rinsing' SOP was established, reducing cleaning time by 60% and nearly eliminating black speck rejection rates in customer inspections.
Technical Specifications
| Model | Power | Overall Dimensions (L×W×H)(mm) | Stainless Steel Soaking Tank Dimensions (L×W×H)(mm) | Hot Water Boiler | Operating Temperature |
|---|---|---|---|---|---|
| GQX-3 | 12.37kw | 13755 × 8519 × 3776 | 6116 × 5005 × 750 (Accommodates 3 x 28-box trolleys) | 30×10⁴ kcal/h | 60°C - 80°C |
